HS485HB Standard Deluxe Sx, Karbonite Gear, BB
HS485HB Standard Deluxe Sx, Karbonite Gear, BB
HS485HB Standard Deluxe Sx, Karbonite Gear,BB
Hitec Servo Specification Chart.
Dimensions (LxWxH): | 1.50" x 0.8"x 1.4" |
Weight: | 1.4oz (39g) |
Operating Speed (4.8V): | 0.23sec/60 degrees at no load |
Operating Speed (6.0V): | 0.18sec/60 degrees at no load |
Stall Torque (4.8V): | 61 oz/in. (4.3kg.cm) |
Stall Torque (6.0V): | 76 oz/in. (5.5kg.cm) |
Operating Voltage: | 4.8-6.0 Volts |
Current Drain (4.8V): | 8mA/idle and 150mA no load operating |
Current Drain (6.0V): | 8.8mA/idle and 180mA no load operating |
Bearing Type: | Top Ball Bearing, Lower Bushing |
Gear Type: | Karbonite Gears |
Motor Type: | 3 Pole Ferrite Motor |
Potentiometer Drive: | Indirect Drive |
Control System: | +Pulse Width Control 1500usec Neutral |
Required Pulse: | 3-5 Volt Peak to Peak Square Wave |
Operating Temperature Range: | -20 to +60 Degree C |
Operating Angle: | 45 Deg. one side pulse traveling 400usec |
360 Modifiable: | Yes |
Direction: | Clockwise/Pulse Traveling 1500 to 1900usec |
Dead Band Width: | 8usec |
Connector Wire Length: | 11.81" (300mm) |
